Chains manufactured by Group company Precision Chains in England.
In cement and Quarry operations reception feeder chains are employed in bulk delivery of materials from trucks, railway wagons or front end loaders. Chains all conform to British Standard BS4116 and are a speciality production for Group company Precision Chains. Surge delivery demands chains of robust construct ion and specifications suitable for this uniquely demanding application. Precision have the expertise to produce best quality chains with proven performance.
Rollers with ball races available as an optional extra.
|
Bulk Reception Chains B Series |
||||||||||||||||
|
Chain |
Pitch |
Rollers |
Bushings |
Pins |
Between Sidebars |
Sidebars |
A |
S3 |
B |
K |
F |
C |
C1 |
Average Ultimate |
||
|
Outside Diameter |
Diameter |
Thickness |
Height |
|||||||||||||
|
P |
D2 |
D5 |
D6 |
L |
S1 |
S2 |
H |
|||||||||
|
mm |
kN |
|||||||||||||||
|
B16/390/A2X2 |
101.6 |
66.68 |
33.02 |
26.92 |
25.4 |
10.0 |
10.0 |
50.8 |
13.0 |
6 |
54.76 |
94.26 |
25 |
50 |
– |
390 |
|
B20/450/A2X2 |
127.0 |
76.20 |
38.10 |
28.60 |
38.1 |
12.7 |
10.0 |
65.4 |
14.0 |
12 |
83.75 |
131.75 |
40 |
70 |
40.6 |
450 |
|
B24/450/A2X1 |
152.4 |
88.90 |
30.10 |
23.00 |
38.1 |
12.7 |
10.0 |
65.4 |
14.0 |
12 |
83.75 |
133.96 |
40 |
65 |
– |
450 |
|
B24/800/A2X1 |
152.4 |
88.90 |
37.95 |
28.58 |
38.1 |
12.7 |
12.7 |
76.2 |
21.0 |
12 |
94.5 |
146.5 |
40 |
65 |
– |
800 |
|
B32/1600/A2X1 |
203.2 |
101.60 |
50.80 |
40.00 |
50.0 |
25.0 |
20.0 |
76.2 |
19.5 |
12 |
133 |
175 |
60 |
100 |
– |
1600 |
Grease lubrication is included as standard unless otherwise advised.
Note recommended lubricant JKG1436M.
