Kings greatest strength lies in the extensive metallurgical experience notably in chains of cast construction. This series is available in standard
JK/WRI or wider variety of materials enhanced through alloy addition finally to full austenitic stainless steel. Where the pintle class chains include a pressed bushing this allows for a combination of materials to maximise suitability and economy.

Cast Link Chains for Intercarriers and Sugar Mill applications

STYLE A

Cast Link Chains for Intercarriers and Sugar Mill applications - Style A

STYLE B

Cast Link Chains for Intercarriers and Sugar Mill applications - Style B

Cast Link Chains for Intercarriers and Sugar Mill applications

Chain
Number

Style

Pitch

Bush Diameter

Pin Diameter

Sidebar Thickness

Over Pin

Bolt Diameter

A

B

H1

H2

Working
Load

Breaking Load

P

D5

D6

S

F

D

JK5174E4

mm

A

59.94

28.58

12.70

7.87

139.70

9.52

25.40

41.28

19.05

15.88

1,500 kg

10,200 kg

in

2.36

1.13

0.50

0.31

5.50

0.38

1.00

1.63

0.75

0.63

3,300 lb

22,500 lb

JK901E41/E44

mm

B

79.98

35.27

15.88

9.65

139.70

12.70

27.69

44.45

23.80

18.29

4,200 kg

11,360 kg

in

3.15

1.31

0.63

0.38

5.50

0.50

1.09

1.75

0.72

0.94

4,150 lb

25,000 lb

JK902E41/E44

mm

B

79.98

33.27

15.88

9.65

141.22

9.52

37.08

23.80

18.29

4,200 kg

11,360 kg

in

3.15

1.31

0.63

0.38

5.56

0.38

1.46

0.72

0.94

4,150 lb

25,000 lb

JK907E51

mm

B

80.52

33.27

15.88

9.65

141.22

9.52

37.60

23.80

18.29

4,200 kg

11,360 kg

in

3.17

1.31

0.63

0.38

5.56

0.38

1.48

0.72

0.94

4,150 lb

25,000 lb
