Metric Conveyor Chains ISO 1977 (M Series) DIN 8167

Chain
Number

P

Working
Load

Average
Weight

Rollers

Pins

Over All Pin & Cotter

Bushings

Between
Sidebars

Sidebars

Style

Flange
thicknes

Diameter

Diameter

Thickness

Height

Bush Type

D1

D2

D4

G

D6

F1

D5

L

S

H

mm

kN

kN*

kg/m

mm

M112

80

112

175

6.30

30

60

75

7.5

15

63

21

32

6

40

M112

100

112

175

5.60

30

60

75

7.5

15

63

21

32

6

40

M112

125

112

175

5.80

30

60

75

7.5

15

63

21

32

6

40

M112

160

112

175

5.37

30

60

75

7.5

15

63

21

32

6

40

M112

200

112

175

4.63

30

60

75

7.5

15

63

21

32

6

40

M160

100

160

260

9.80

36

70

90

8.5

18

72

25

37

7

50

M160

125

160

260

8.50

36

70

90

8.5

18

72

25

37

7

50

M160

160

160

260

7.80

36

70

90

8.5

18

72

25

37

7

50

M160

200

160

260

7.30

36

70

90

8.5

18

72

25

37

7

50

M160

250

160

260

6.90

36

70

90

8.5

18

72

25

37

7

50

M224

125

224

340

12.30

42

85

105

10

21

84

43

43

8

60

M224

160

224

340

11.10

42

85

105

10

21

84

43

43

8

60

M224

200

224

340

10.20

42

85

105

10

21

84

43

43

8

60

M224

250

224

340

6.90

42

85

105

10

21

84

43

43

8

60

M224

315

224

340

8.98

42

85

105

10

21

84

43

43

8

60

M315

160

315

520

19.20

50

100

124

10.5

25

97

48

48

10

70

M315

200

315

520

16.70

50

100

124

10.5

25

97

48

48

10

70

M135

250

315

520

15.60

50

100

124

10.5

25

97

48

48

10

70

M315

315

315

520

14.70

50

100

124

10.5

25

97

48

48

10

70

M315

400

315

520

13.80

50

100

124

10.5

25

97

48

48

10

70

* Breaking Load With heat treated Plates


This is for guidance Only. Additonal sizes according to FV standard Din8165 and variations on both series are available.
Contact John King Technical for further clarification.
