Maxi Chains – King Works Standard

This John Kings works standard includes a range of crank link steel bush chains that offer maximum versatility either in conveying or elevating applications. This series was originally developed to offer an all steel direct replacement for the Cast Bush and Pintle chains. Materials employed, with case hardened alloy steel pin and bush ensure reliable performance.

The crank link construction is a more convenient and effective style. One link can be added or removed if chain length is altered. Any variety of attachments can be fabricated and welded to the base chain. This is generally K style but other styles of attachments can also be provided.


Maxi Chains – King Works StandardMaxi Chains – King Works Standard

Maxi Series 5 K1 attachments | Maxi Series 5 K2 attachments | Maxi Series 6 K1 attachments | Maxi Series 6 K2 attachments A Style

Maxi Chains – King Works Standard

Chain
Number

Pitch

Over-all
Pin & Cotter

Pin Diameter

Bushing
Outside Dia.

Between
Sidebars

Sidebars

Thickness

Height

Average
Ultimate
Strength

Average
Weight

P

F1

D6

D5

L

S

H

mm

kg

kg/m

MX603

76.2

88

14

22.5

38

8

40

20,000

11.02

MX503

76.7

86

14

22.7

38

8

40

20,000

9.25

MX604

101.6

79

16

25

57

10

50

27,500

14.92

MX704

101.6

70

16

30

50

10

50

35,000

22.63

MX504

103.7

147.6

16

33

50

10

50

27,500

12.66

MX600

153.4

110

18

28.6

50

10

50

30,000

15.51

MX500

153.5

92

16

38

50

10

50

25,000

8.95
