Combination Eleveyor Chains

For grain eleveyors where the product is transported from the horizontal up a “swan neck” this is commonly seen to employ the cast combination chain with an F attachment. To the attachment a wiper blade is fixed which acts as the conveying medium. Three standards are typical as OEM replacements but a variety of widths can be produced if so required.


Combination Eleveyor Chains

Combination Eleveyor Chains

Chain Number

P

Breaking Load

Average Weight

Bushings

Between Sidebars

Gearing

Sidebars

Pin Diameter

Overall Width

Overall Flight Height

Outside Diameter

Thickness

Height

D5

L

G

S1

S2

H

D6

IX

F

mm

lbs

kg/m

mm

C664/F4X190

66.4

12,000

6.98

23

37

25

5

8

20

11

190

90

C664/F4X210

66.4

12,000

7.12

23

37

25

5

8

20

11

210

90

C762/F4X280

76.2

24,000

12.8

32

43

30

6

10

30

14

280

115
