European Standard Cast Link Drag Chain (JKD)


Cement, European Standard Cast Link Drag Chain (JKD)


European Standard Cast Link Drag Chain (JKD)

Chain
Number

Pitch

Width

Width over flight

Bearing Length

Sidebars

Overall Height

Pins dia.

Gearing width

Average weight

Ultimate Tensile Strength

Thickness

Height

P

F1

IX

B

S

H

S1

D6

L

mm

kg/m

kN

JKT150/40/Tx125

150

86

125

40

15

40

50

18

64

13.2

250

JKT200/50/Tx200

200

100

200

49

20

40

44

18

76

13.3

250

JKT200/50/Tx300

200

100

300

49

20

40

44

18

76

18.3

250

JKT225/50/Tx250

225

122

250

50

25

60

60

25

87

35.8

550

JKD200/180/Tx250

200

222

250

180

15

40

55

19

96

21.7

250

JKD200/180/Tx300

203.2

222

302

180

17

40

52

20

127

24.5

275

200

222

300

180

20

40

55

18

96

23.4

250

JKD200/180/Tx315

200

225

315

180

16

40

53

18

106

26.5

250

JKD200/180/Tx600

200

232

600

180

15

40

55

19

110

37.0

250

JKD200/220/Tx450

200

285

450

220

20

50

60

25

154

51.0

550

JKD200/220/Tx500

203.2

290

504

222

21

48

61

25.4

163

59.3

550

JKD200/285/Tx650

203.2

375

650

285

26

60

80

30

410

82.2

750

JKD200/200/Tx350

215

254

345

196

18

42

42

25

123

30.0

550

JKD230/220/Tx320

230

320

320

216

30

60

60

28

156

36.3

700

JKD230/320/Tx460

228.6

457

457

320

25.4

63.5

63.5

31.75

246

64.0

800

JKD230/340/Tx405

228

405

405

341

18

66

73

PINLESS

235

51.8

1250

JKD250/230/Tx450

250

312

450

228

22

90

90

36

152

78.0

1250

JKD270/380/Tx650

271

506

650

380

37

90

105

50

290

146.5

1500

JKD280/180/Tx300

280

215

300

180

15

40

55

20

110

20.0

250

JKD295/380/Tx600

295

463

600

377

40

90

90

36

290

135

1250

JKD350/380/Tx600

350

492

600

380

52.5

104

135

46

290

145

1500

JKD400/580/Tx800

400

690

800

578

45

104

135

46

415

190

1500

400

690

800

580

33

90

104

45

468

145

1500
