Oven Chains – Solid Pin Cranked Sidebar



Oven Chains – Solid Pin Cranked Sidebar

Oven Chains – Solid Pin Cranked Side Bars

Chain
Number

P

Breaking
Load

Rollers

Bushings

Between
Sidebars

Sidebars

Pins

Attachment

Dia.

Outside Diameter

Thickness

Height

Diameter

D2

D5

L

L1

S

H

D6

D7

mm

kN

mm

SP200/1524/B/A5X/P

152.4

200

120.7

38.1

44.4

90

8

70

31.8

19.05

SP200/1778/B/A5X/P

177.8

200

120.7

38.1

44.4

90

8

70

31.8

19.05

SP200/2286/B/A5X/P

228.6

200

120.7

38.1

44.4

90

8

70

31.8

19.05

Note: A5 attachement to be left & right hand. Chain supplied in matched strands.
